Tech Specification
|
 |
 |
 |
 |
 |
 |
Specification
| Model Name: |
TENDA AC6 AC1200 SMART DUAL-BAND WIRELES |
| Brand: |
TENDA |
| Color: |
Black |
| Certification: |
CE/FCC/RoHS |
| Standard&Protocol: IEEE802.3, IEEE802.3u |
|
| Interface: |
1*10/100Mbps WAN port | 3*10/100Mbps LAN ports |
| Antenna: |
4*5dBi external antennas |
| Button: |
1*WiFi on/off, 1* Reset/WPS button |
| Power: |
Input：100-240V—50/60Hz, 0.2A | Output：DC 12V==1A |
| Dimension: |
220*141.5*49mm |
| LED: |
System*1,WAN*1, LAN*1, 2.4G*1, 5G*1,WPS*1 |
| Wireless Standards: |
IEEE 802.11ac/a/n 5GHz | IEEE 802.11b/g/n 2.4GHz |
| Data rate: |
5GHz: Up to 867Mbps | 2.4GHz: Up to 300Mbps |
| Frequency: |
Simultaneous dual band 2.4 & 5GHz |
| Transmit Power: |
CE: <20dBm(2.4G) | <23dBm(5G) FCC: <30dBm |
| Basic Features: |
SSID Broadcast: Enable/Disable Transmission Power: high, medium, low Beamforming |
| Wireless Security: |
WPA-PSK/WPA2-PSK, WPA/WPA2 | Wireless Security: Enable/Disable | WPS(WiFi Protected Set-up) fast encryption |
| Internet Connection Type: |
PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) |
| Operating Mode: |
Wireless Router Mode | Universal Repeater Mode | WISP Mode |
| DHCP Server: |
DHCP Server | DHCP Client List | DHCP Reservation |
| Virtual Server: |
Port Forwarding | DMZ Host | UPnP |
| Security: |
Client Filter | Parental Control(support black list and white list) | Remote Web Management |
| Firewall: |
Forbid UDP flood attack | Forbid TCP flood attack | Forbid flood attack | Forbid WAN PING from internet |
| DDNS: |
Support DynDNS, No-ip, 3322.org, Oray.com, 88ip |
| VPN: |
IPsec pass through | PPTP pass through | L2TP pass through | PPTP server | PPTP client | L2TP client |
| Features: |
Smart WiFi Schedule | Smar10:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/202110:50 AM 1/21/2021t Power Saving | Smart LED on/off | Tenda Cloud | Tenda App |
| Special Features: |
PPPoE Username/password Clone :Smart WiFi Schedule | Smart Power Saving | Smart LED on/off | Tenda Cloud | Tenda App |
| Other: |
Bandwidth Control | Guest Network | IPTV | MAC Clone | System Log | Backup & Restore configurations | Firmware upgrade online | Firmware upgradeable via browser |
| Temperature: |
Operating Temperature: 0℃ ~ 40℃ | Storage Temperature: -40℃ ~ 70℃. |
| Humidity: |
Operating Humidity:10% ~ 90% RH non-condensing | Storage Humidity: 5% ~ 90%RH non-condensing. |
| Default Settings: |
Default Access: tendawifi.com |
| Package Content: |
AC1200 Smart Dual-Band WiFi Router | Power Adapter | Install Guide | Ethernet Cable |
