Tech Specification
|
 |
 |
 |
Specification
| Model Name: | TPLINK DECO E4 (3 PACK) AC1200 WHOLE |
| Brand: | TPLINK |
| Color: | White |
| POWER | |
| AC adapter input: | 100-240V~ 50/60Hz 0.3A |
| AC adapter output: | 12V ⎓ 1A |
| HARDWARE FEATURES | |
| Ports: | 2 10/100Mbps WAN/LAN Ports, 1 Power Port |
| Button: | 1 Reset button on the underside |
| Flash: | 16 MB |
| SDRAM: | 128 MB |
| Dimensions: | ( W x D x H ): 7.5 × 3.6 × 3.6 in. (190.5 × 90.7 × 90.7 mm) |
| Dimensions: | 7.5 × 3.6 × 3.6 in. (190.5 × 90.7 × 90.7 mm) |
| Antenna Type: | 2 internal dual-band antennas per Deco unit |
| WIRELESS FEATURES | |
| Wireless Standards: | IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz |
| Frequency: | 2.4 GHz and 5 GHz |
| Signal Rate: | 867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz |
| Transmit Power: | FCC: <30 dBm, CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz) |
| Wireless Security: | WPA-PSK/WPA2-PSK |
| SOFTWARE FEATURES | |
| Quality of Service: | WMM |
| WAN Type: | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
| Management: | Local Management, Remote Management |
| DHCP: | Server, Client |
| Firewall Security: | SPI Firewall |
| Protocols: | Supports IPv4 and IPv6 |
| Guest Network: | 2.4 GHz guest network x 1, 5 GHz guestnetwork x 1 |
| Working Modes: | Router, Access Point |
| OTHERS | |
| Certification: | CE, FCC, IC, NCC, BSMI, IDA,RCM, JPA, JRF, VCCI, KC, RoHS |
| Package Contents: | 3 Deco units | 3 Power Adapters : 1 RJ45 Ethernet Cable |
| Smartphone/Tablet Requirements: | iOS 9.0 or later, Android 4.4 or later |
| Environment: | Operating Temperature: 0℃~40℃ (32℉~104℉) | Storage Temperature: -40℃~70℃ (-40℉~158℉) | Operating Humidity: 10%~90% non | condensing |
| Storage Humidity: | 5%~90% non-condensing |
